High Quality High Air Permeability Polyester Sludge Dewatering Belt For Chemical Industry
Polyester Sludge Dewatering Belt Introduction
The anti-alkali belt can be used as filter mesh in high temperatures, the material with
alkali content(sodium hydroxide) ≥ 20%. And it's also used in some industries that
need high tensile strength and high wear resistance
Polyester sludge dewatering belt have the characteristics of good water permeability
air permeability and non-revealed sludge, acid-resisting and alkali-resisting. Because
of their designing structure, the sludge can be peel off easily from the filter cake so the screen
are easily cleaned and have a long working time. Mainly matching with belt type filter press
vacuum rubber belt filter and vacuum horizontal belt filter
Polyester Sludge Dewatering Belt Features
| Name |
Acid-resisting 100%Polyester Mesh Belt Durable For Paper Sludge Dewatering |
Color |
White, Blue, Red |
| Keyword |
Polyester Mesh Belt |
Application |
Sludge Dewatering Belt |
| Material |
100%Polyester |
Joint |
Endless,Steel-clip,Spiral Ring |
| High Light |
mesh material fabric
,
plain weave mesh
|
Polyester Sludge Dewatering Belt Advantage
1 Good permeability air permeability
2 Non-revealed sludge
3 Acid-resisting alkali-resisting heat resistance(180 °C)
4 Because of their designing structure, the sludge can be peel off easily after pigeonhole filter
so the screen are easily cleaned and have a long working time
5 Therefore they are designed specially for sludge dehydration
6 To make the culture paper, printing paper, and packing paper
7 Filled or unfilled to achieve different filtration characteristics
Polyester Sludge Dewatering Belt Date Sheet
| Model |
Wire Diameter |
Density Root/10cm |
Air Permeability m3/m2h |
Net Weight g/m2 |
Strength kg/cm |
Used in |
| Wrap |
Weft |
Wrap |
Weft |
| 14803 |
0.7 |
0.8 |
142 |
47-60 |
3900-8500 |
1400 |
240 |
Sludge,Squeeze juice |
| 16803 |
0.7 |
0.8 |
156 |
46-50 |
6000 |
1400 |
265 |
Sludge,Squeeze juice |
| 16904 |
0.75 |
0.9 |
156 |
47 |
8000 |
1800 |
280 |
Iron and steel industry sludge dewatering Living slude dewatering |
| 121054 |
0.9 |
1.05 |
120 |
42 |
8000 |
1650 |
340 |
Iron and steel industry sludge dewatering |
| 22903 |
0.5 |
0.9 |
220 |
50-55 |
9000 |
1200 |
200 |
Living slude dewatering |
| 20703 |
0.5 |
0.7 |
200 |
70 |
10000 |
1000 |
185 |
Living slude dewatering |
| 24504 |
0.5 |
0.5 |
240 |
130-140 |
8500 |
1180 |
220 |
Paper dry network |
| 8903 |
0.9 |
0.9 |
78 |
50 |
8500 |
1430 |
210 |
industrial sludge dewatering |
| 16704 |
0.7 |
0.7 |
160 |
90 |
12000 |
1350 |
165 |
Building materials dewatering |
| 26908 |
0.5 |
0.9 |
26.4 |
69-75 |
5000 |
1364 |
240 |
Viscosit of the larger |
| 12 Mesh |
0.75 |
0.8 |
47 |
48 |
|
650 |
94 |
Paper pulp washing |
Polyester Sludge Dewatering Belt Advantage Packing detail
- Wooden case is the best for ocean shipment because it can effective avoid the damage during shipping
- There also have some customer request us to use the carton to packing their goods
- We can according to customer's requirement
