Product Details:
Payment & Shipping Terms:
|
| Material: | 100%polyester | Color: | White Blue |
|---|---|---|---|
| Type: | 16903 22903 | Usage: | Sludge Dewatering, Press Filter, Juice |
| Width: | 0.2-3.2meters | Length: | 10-100meters |
| Feature: | Easy Clean | Advantage: | Long Service Time |
| High Light: | horizontal polyester sludge dewatering belt,3.2meters width polyester sludge dewatering belt,molybdenum water treatment polyester mesh belt |
||
Horizontal Type Polyester Mesh Belt Filters Screen For Molybdenum Gold Silver Minerals Sludge Water Treatment
Production Introduction:
Polyester Sludge Dehydration Fabrics is also called press-filter Fabrics which is mainly used for sludge dehydration, paper pulp and juice squeeze, mine smelting, mine tailing disposal and other pressure filtration industries.
They have the characteristics of good water permeability and non-revealed sludge, acid-resisting and alkali-resisting. Because of their designing structure, The sludge can be peel off easily from the filter cake, So the screen are easily cleaned and have a long working time.
Mainly matching with belt type filter press, vacuum rubber belt filter and horizontal vacuum belt filter.
Featrue:
1) High strength,good water permeabilty
2) High temperture resistance under 180 degrees
3) Shrink-resistant
4) Acid,alkali resistance
|
Type
|
Wire Diameter(mm) | Density/cm |
Strength(N/cm) Tensile strength |
Weight kg/m2 |
Thickness mm |
Air Permeability m3/m2h |
|||
| Warp | Weft |
Warp |
Weft |
Surface | Joint | ||||
| RK27708 | 0.50 | 0.70 | 28 | 8.5 | 1600 | 900 | 1.53 | 2.0 | 4896 |
| RK26908 | 0.50 | 0.90 | 26.2 | 6.2 | 1600 | 900 | 1.49 | 2.15 | 6080 |
| RK24908 | 0.50 | 0.90 | 24.8 | 7.1 | 1600 | 900 | 1.48 | 2.1 | 7360 |
| RK24808 | 0.50 | 0.80 | 24.8 | 8 | 1600 | 900 | 1.4 | 2.0 | 6880 |
| RK16903 | 0.70 | 0.90 | 16.3 | 5 | 1600 | 900 | 1.5 | 2.1 | 7520 |
| RK16903 | 0.70 | 0.90 | 16.3 | 5.8/6 | 1600 | 900 | 1.7 | 2.1 | 5550/3980 |
| RK15905 | 0.90 | 0.90 | 15.3 | 5 | 1600 | 900 | 2.1 | 2.77 | 7840 |
| RK151105 | 0.90 | 1.10 | 15.3 | 6.3 | 1600 | 900 | 2.45 | 2.85 | 9280 |
| RK12904 | 0.90 | 0.90 | 12.3 | 9.5 | 1600 | 900 | 2.2 | 3.5 | 9600 |
