| Name: | JPP Nylon Filter Mesh With 37 Micron Plain Weave 127 Cm Width Roll | Color: | White Yellow |
|---|---|---|---|
| Mesh Count: | 305 Inch | Thread Diameter: | 43 Um |
| Mesh Opening: | 37 Um | Thickness: | 70 Um |
| Material: | 100% Nylon | Usage: | Filter |
| Length: | 50 Meters | Width: | 127cm |
| High Light: | 37 micron nylon filter mesh,127cm width roll nylon filter mesh,plain weave nylon filter cloth mesh |
||
Our polyester nylon filter screen mesh is divided into different meshes COUNT and different wire diameters, which is the number of threads in ordinary times. The number of threads in the fabric refers to the number of threads per inch. Our nets are flat woven with uniform square holes. The warp threads extend longitudinally in the fabric. The weft or weft crosses the width of the fabric at right angles to the fabric. Since the monofilament fabric produced has the same yarn diameter and the same count in the warp and weft directions, the mesh is square.
Nylon mesh filter roll can make nylon filter bags(nut milk filter bag ,juice filter beer filter, ) filter piece, and dust-proof bag, rosin filter bags.
Nylon mesh also widely used in medician,petroleum,
Features of thre nylon filter mesh roll:
High durability,
Beautiful appearance and standard size
Clean and never fade.
Fast turnaround time from the screen room to the newsroom
Good heat permeability.
High air permeability
Acid and alkali resistance.
long working life and wear resistance
Specification of the nylon filter mesh roll:
| Fabric number | Mesh count | Thread diameter | Mesh opening | Opening | Thickness | |
| No. | cm | inch | um | micron | % | um |
| JPP5 | 5 | 12 | 500 | 1500 | 56 | 850 |
| JPP6 | 6 | 16 | 400 | 1267 | 58 | 780 |
| JPP7 | 7 | 18 | 350 | 1079 | 57 | 675 |
| JPP8 | 8 | 20 | 350 | 900 | 52 | 685 |
| JPP9 | 9 | 24 | 250 | 861 | 60 | 455 |
| JPP10 | 10 | 25 | 300 | 700 | 49 | 576 |
|
JPP12 |
12 | 30 | 250 | 583 | 49 | 470 |
| 12 | 30 | 300 | 533 | 41 | 585 | |
| JPP14 | 14 | 35 | 250 | 464 | 42 | 470 |
|
JPP16 |
16 | 40 | 200 | 425 | 46 | 370 |
| 16 | 40 | 250 | 375 | 36 | 485 | |
|
JPP20 |
20 | 50 | 150 | 350 | 49 | 375 |
| 20 | 50 | 200 | 300 | 36 | 385 | |
| JPP24 | 24 | 60 | 150 | 267 | 41 | 285 |
| JPP28 | 28 | 70 | 120 | 237 | 44 | 215 |
| JPP30 | 30 | 76 | 120 | 213 | 41 | 225 |
| JPP32 | 32 | 80 | 100 | 213 | 46 | 165 |
| JPP36 | 36 | 90 | 100 | 178 | 41 | 178 |
| JPP40 | 40 | 100 | 100 | 150 | 36 | 190 |
| JPP40 | 40 | 100 | 120 | |||
| JPP43 | 43 | 110 | 80 | 152 | 43 | 135 |
| JPP48 | 48 | 120 | 80 | 128 | 38 | 145 |
| JPP56 | 56 | 140 | 61 | 118 | 44 | 85 |
| JPP59 | 59 | 150 | 61 | 109 | 41 | 98 |
| JPP64 | 64 | 160 | 61 | 95 | 37 | 105 |
| JPP72 | 72 | 180 | 50 | 89 | 41 | 82 |
| JPP80 | 80 | 200 | 50 | 75 | 36 | 90 |
| JPP100 | 100 | 250 | 43 | 57 | 32 | 65 |
| JPP120 | 120 | 305 | 43 | 40 | 23 | 70 |
