Product Details:
Payment & Shipping Terms:
|
| Product Name: | Short Roll Food Grade 90 100 200 Micron Nylon Filter Mesh Flour Mesh Sieve Mesh | Hole Shape: | Square |
|---|---|---|---|
| Usage: | Liquid Filter | Weave Style: | Plain Woven Nylon Mesh |
| Technique: | Woven | Feature: | Corrosion Resistance |
| Width: | 1-3.65m | Mesh Count: | 12-600 Mesh |
| Material: | Nylon | Length: | 30-70m/roll |
| High Light: | fda Nylon Filter Mesh,90 micron Nylon Filter Mesh,200 micron Nylon Filter Mesh |
||
Short Roll Food Grade 90 100 200 Micron Nylon Filter Mesh Flour Mesh Sieve Mesh
Product Introduction
Material:FDA food grade commercial nylon mesh
Mesh opening:5-1950 micron
Weave Style:Plain Weave
Thread Diameter:31-550 micron
Monofilament Style:Yes
Thickness:51-1100 micron
Hole Shape:square
Roll length:30-70m or customized
Roll width:1m, 1.25m, 2.5m, 2.95m or customized
Usage:liquid filter, air filter, dust filter
Type:filter mesh, filter cloth, mine sieving mesh, filter disc, filter cylinder
Product Features
5–236 meshes for different filtration requirements.
Available for filter disc, filter tube, filter belt and filter bags.
Plain weave or twill weave options.
Excellent in liquid, powder, dust, gas and other element filtration.
Alternative to polyester (PA) filter mesh.
Product Application
Nylon filter mesh are widely used in:
Mining
Agriculture
Aquaculture
medical and laboratory.
infusion and transfusion filters
micro-aggregate filters
arterial and venous filters in oxygenator reservoirs and blood bag
Making nylon filter bags
Product Characteristic
| Fabric number | Mesh count | Thread diameter | Mesh opening | Opening | Thickness | Weight | |
| No. | cm | inch | um | micron | % | um | g/m2 |
| JPP4 | 4 | 10 | 550 | 1950 | 61 | 950 | 262 |
| JPP5 | 5 | 12 | 500 | 1500 | 56 | 850 | 271 |
| JPP6 | 6 | 16 | 400 | 1267 | 58 | 780 | 208 |
| JPP7 | 7 | 18 | 350 | 1079 | 57 | 675 | 186 |
| JPP8 | 8 | 20 | 350 | 900 | 52 | 685 | 212 |
| JPP9 | 9 | 24 | 250 | 861 | 60 | 455 | 145 |
| JPP10 | 10 | 25 | 300 | 700 | 49 | 576 | 195 |
| JPP12 | 12 | 30 | 250 | 583 | 49 | 470 | 162 |
| 12 | 30 | 300 | 533 | 41 | 585 | 234 | |
| JPP14 | 14 | 35 | 250 | 464 | 42 | 470 | 190 |
| JPP16 | 16 | 40 | 200 | 425 | 46 | 370 | 139 |
| 16 | 40 | 250 | 375 | 36 | 485 | 217 | |
| JPP20 | 20 | 50 | 150 | 350 | 49 | 375 | 98 |
| 20 | 50 | 200 | 300 | 36 | 385 | 173 | |
| JPP24 | 24 | 60 | 150 | 267 | 41 | 285 | 117 |
| JPP28 | 28 | 70 | 120 | 237 | 44 | 215 | 87 |
| JPP30 | 30 | 76 | 120 | 213 | 41 | 225 | 94 |
| JPP32 | 32 | 80 | 100 | 213 | 46 | 165 | 69 |
| JPP36 | 36 | 90 | 100 | 178 | 41 | 178 | 78 |
| JPP40 | 40 | 100 | 100 | 150 | 36 | 190 | 87 |
| JPP43 | 43 | 110 | 80 | 152 | 43 | 135 | 60 |
| JPP48 | 48 | 120 | 80 | 128 | 38 | 145 | 62 |
| JPP56 | 56 | 140 | 61 | 118 | 44 | 85 | 44 |
| JPP59 | 59 | 150 | 61 | 109 | 41 | 98 | 46 |
| JPP64 | 64 | 160 | 61 | 95 | 37 | 105 | 50 |
| JPP72 | 72 | 180 | 50 | 89 | 41 | 82 | 39 |
| JPP80 | 80 | 200 | 50 | 75 | 36 | 90 | 43 |
| JPP100 | 100 | 250 | 43 | 57 | 32 | 65 | 35 |
| JPP120 | 120 | 305 | 43 | 40 | 23 | 70 | 42 |
| JPP130 | 130 | 330 | 43 | 34 | 20 | 75 | 45 |
| JPP140 | 140 | 355 | 38 | 33 | 21 | 67 | 48 |
| JPP150 | 150 | 380 | 38 | 29 | 19 | 68 | 51 |
| JPP165 | 165 | 420 | 35 | 26 | 18 | 62 | 47 |
Non-toxic,odorless,tasteless,high strength,high elongtation
wear resistant ,high strength,good filtration(high air permeability)
Service long life time.
Bulk mesh in stock.
sample are available for you.
Custom-make.(quantity,color, width and so on,as your request)
we are the big stable factory,welcome you to visit our plant.
Product Features
| It has high tension threshold and breaking point |
| It has high modulus, low elongation monofilament nylon yarn |
| It has resist to chemicals, abrasion, heat and moisture |
| Minimal tension loss during stretching process |
| Improved registration due to stable fabric tension |
| Good antistatic |
| No surface treatment |
Mesh Count is the number of threads per inch in the direction of warp and weft of the fabric.The mesh count is indentical in both warp and weft direction for Share Fitration's woven mesh.
Thread Diameter is specified as the diameter of the thread in microns.Yarn sizes in both warp and weft directions are the same.
Mesh Opening is the size or space between threads.The mesh opening is the result of the combination of the mesh count and yarn size.Mesh opening will determine the size or amount of material that will pass through the fabric.
Product Package
1. We always use poly bag for the goods which ship by air, so that customer can save freight free
2. Wooden case is the best for ocean shipment, because it can effective avoid the damage during shipping
3. There also have some customer request us to use the carton to packing their goods
4. We can according to customer's requirements
