Product Details:
Payment & Shipping Terms:
|
Weight: | 0.2kg | Papermaking Weight: | 1.1kg/m2、1.4kg/m2、1.7kg/m2、1.9kg/m2 |
---|---|---|---|
Papermaking Strength (N/cm): | 1.7-3mm | Air Infiltration: | 4550-9000 (m3/m2) |
Highlight: | 4550-9000 m3/m2 Polyester Molded Fabric,Paper Machine Mills Polyester Molded Fabric,0.2kg Polyester Molded Fabric |
Parameter table
Wire Diameter(mm) |
Tensile Strength (N/cm) |
Weight Kg/m² |
Thickness mm |
Air Permeability m³/m²h |
CFM 127/pa |
||
Spiral wire |
Connection wire |
Filter material monofilament |
|||||
0.50 | 0.80 | 0.60*3 | 1800 | 1.50 | 2.1 | 4480 | 280 |
0.68 | 0.90 | 0.80*4 | 2000 | 2.0 | 2.45 | 6080 | 380 |
0.68 | 0.90 | 0.90*3 | 2000 | 190 | 2.45 | 5760 | 360 |
0.68 | 0.90 | 0.80*3 | 2000 | 1.85 | 2.45 | 7750 | 484 |
0.68 | 0.90 | Flat wire2.10.80 | 2000 | 1.80 | 2.45 | 9oo⁰ | 563 |
0.68 | 0.90 | Flat wire2.40.88 | 2000 | 1.85 | 2.45 | 8000 | 500 |
0.68 | 0.90 | Conductive carbon wire | 2000 | 1.60 | 2.45 | 10000 | 625 |
0.90 | 0.90 | 0.90*3 | 2300 | 2.30 | 3.03 | 7500 | 468 |
0.90 | 1.10 | 1.04 | 2000 | 2.40 | 3.15 | 6240 | 390 |
0.90 | 1.10 | 1.23 | 2000 | 2.25 | 3.15 | 6240 | 390 |
1.0 | 0.90 | 1.0*3 | 2000 | 2.50 | 3.60 | 5000 | 315 |
1.20 | 1.30 | 1.2'3 | 2600 | 2.85 | 4.30 | 7500 | 468 |
1. Superior Strength: Exhibits high tensile and abrasion resistance, ensuring long - lasting performance.
2. Chemical Stability: Resistant to acids, alkalis, and most chemicals, suitable for harsh environments.
3. Precise Filtration: Offers consistent mesh openings for accurate separation and efficient filtration.
4. Thermal Resistance: Maintains dimensional stability under a wide temperature range, preventing deformation.
5. Easy Maintenance: Smooth surface reduces clogging, facilitating cleaning and extending service life.
6. Cost - Effective: High durability and low replacement frequency bring long - term economic benefits.
