Steel Card Interface Polyester Sludge Dewatering Belt For City Dedicated
Polyester Sludge Dewatering Belt Product Introduction
This kind of polyester mesh belt is specially designed for waste water treatment systems
as a sludge dewatering belt Sludge dewatering belt is mainly used for belt type press filter
rubber belt vacuum filter horizontal belt vacuum filter,especially for the drying process in paper milll
also used at criticalstages of particle board, medium density fibreboard (MDF), manufacture of ceiling tiles etc
Sludge dewatering belt is made of round or flat threads,excellent permeation of air and
water while keeping out the sludge Applicable to the municipal sewage sludge sludge
filtrationenterprises press paper mill pulp the use of concentrated fruit juice squeezing and
other special industry Due to its unique structure,the sludge is easy to peel off and
clean after the sludge is pressed and filtered,not sticky mud
| Model |
wire diameter
mm |
Density/cm |
Air Permeability
m3/m2h |
Weight
g/㎡ |
Tensile
kg/cm |
Application |
| Warp |
Weft |
Warp |
Weft |
| WNW14803 |
0.7 |
0.8 |
142 |
47-60 |
3900-
8500 |
1400 |
240 |
Sludge dewatering, fruit squeezing |
| WNW16803 |
0.7 |
0.8 |
156 |
46-50 |
6000 |
1400 |
265 |
Sludge dewatering, fruit squeezing |
| WNW16904 |
0.75 |
0.9 |
156 |
47 |
8000 |
1800 |
280 |
Sludge dewatering in the iron and steel industry |
| WNW121054 |
0.9 |
1.05 |
120 |
42 |
8000 |
1650 |
340 |
Sludge dewatering in the iron and steel industry |
| WNW22903 |
0.5 |
0.9 |
220 |
50-55 |
9000-
10000 |
1200 |
200 |
Dewatering of domestic sludge |
| WNW20703 |
0.5 |
0.7 |
200 |
70 |
10000 |
1000 |
185 |
Dewatering of domestic sludge |
| GW24504 |
0.5 |
0.5 |
240 |
130-140 |
8500-
10000 |
1180 |
220 |
Paper industry |
| WNW08903 |
0.9 |
0.9 |
78 |
50 |
8500 |
1430 |
210 |
Paper industry |
| WNW16704 |
0.7 |
0.7 |
160 |
90 |
12000 |
1350 |
265 |
Building Materials Industry
|
Polyester Sludge Dewatering Belt Product Introduction Description
- Applicable Industries Energy & Mining Food & Beverage Shops Advertising Company
- After Warranty Service Video technical support
- Place of Origin Hebei China
- Brand Name R&K
- Type Filter Felt Make-to-order
- Usage Liquid Filter Pulp Making System
- Material Polyester 100% Polyester
- Product Name polyester sprial press filter belt
- Material of roller Polyester Forming Mesh
- Packaging Plywood Case and woven mesh
- Certificate ISO9001
- Surface smooth
Polyester Sludge Dewatering Belt Product Introduction Advantage
- Acid-resisting alkali-resisting heat resistance(180 °C)
- Because of their designing structure, the sludge can be peel off easily after pigeonhole filter, so the screen are easily cleaned and have a long working time
- Therefore they are designed specially for sludge dehydration
- To make the culture paper, printing paper, and packing paper
- Filled or unfilled to achieve different filtration characteristics
- Adhesive edges for lasting, economical solutions
How to choose Polyester Sludge Dewatering Belt
polyester filter belt is widely used inMineral industry -mining sieving mineral separation gold benefication
Paper industry-paper pulps making sulplate pulppacking and cardboard pulp Dryer -Textile yarn
Others -tailings disposal colliery food medicine etc
Polyester Sludge Dewatering Belt Packing detail
| We always use poly bag for the goods which ship by air, so that customer can save freight free |
| Wooden case is the best for ocean shipment, because it can effective avoid the damage during shipping |
| There also have some customer request us to use the carton to packing their goods |
| We can according to customer's requirement |
