Home ProductsPolyester Sludge Dewatering Belt

High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation

China Hebei Reking Wire Mesh Co.,Ltd certification
China Hebei Reking Wire Mesh Co.,Ltd certification
I alreay install the flat flex conveyor belt and works well. Good company with nice service and high quality and high reputation

—— Mervyn Roe

Chain Mesh Conveyor Belt quality is ok. One of our reliable supplier , goods are delivered in time and nice package.

—— Dina Chek

Perfect Flat Wire Conveyor Belt we have purchased, low cost and good service.

—— Bahram Vand

I'm Online Chat Now

High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation

High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation
High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation
video play

Large Image :  High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation

Product Details:
Place of Origin: China
Brand Name: RK
Model Number: 16903
Payment & Shipping Terms:
Minimum Order Quantity: 1square meter
Price: USD12.5-16.8USD/square meter
Packaging Details: woven bag+wooden case
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 square meter per month
Detailed Product Description
Product Name: Polyester Mesh Belt For Waste Water Treatment Material: 100%polyester
Color: White Blue Type: 16903 22903
Usage: Sludge Dewatering, Press Filter, Juice Width: 0.2-3.2meters
Length: 10-100meters Feature: Easy Clean
Advantage: Long Service Time
High Light:

high temperture polyester mesh belt

,

waste water treatment polyester mesh belt

,

solid liquid separation sludge dewatering belt

Waste Water Treatment Solid Liquid Separation Polyester Woven Press Filter Mesh Belt Screen Fabric



Production Introduction:

Polyester Sludge Dehydration Fabrics is also called press-filter Fabrics which is mainly used for sludge dehydration, paper pulp and juice squeeze, mine smelting, mine tailing disposal and other pressure filtration industries.

Sludge Dewatering Belt, is designed for solid liquid separation, especially sludge dehydration in sewage treatment industry. Made of high quality polyester, our range of belt is heat-set at exacting temperature and tensioned to achieve much better operational stability. It is suitable for press belt filter and various vacuum belt filters.



Featrue:

1) High strength,good water permeabilty

2) High temperture resistance under 180 degrees

3) Shrink-resistant

4) Acid,alk



Applications:

Municipal and industrial wastewater treatment plants

Paper mills

Steel and rolling mills

Water treatment systems

Sand and gravel etc.

ali resistance



Product name Polyester mesh belt for water treatment
Type 22903  16903
Color White blue green
Usage waste watertratment
Size width not more than 360cm, length is customzied





Type



Wire Diameter(mm) Density/cm

Strength(N/cm)

Tensile strength



Weight kg/m2



Thickness mm



Air Permeability

m3/m2h

  Warp Weft



Warp



Weft

Surface Joint
RK27708 0.50 0.70 28 8.5 1600 900 1.53 2.0 4896
RK26908 0.50 0.90 26.2 6.2 1600 900 1.49 2.15 6080
RK24908 0.50 0.90 24.8 7.1 1600 900 1.48 2.1 7360
RK24808 0.50 0.80 24.8 8 1600 900 1.4 2.0 6880
RK16903 0.70 0.90 16.3 5 1600 900 1.5 2.1 7520
RK16903 0.70 0.90 16.3 5.8/6 1600 900 1.7 2.1 5550/3980
RK15905 0.90 0.90 15.3 5 1600 900 2.1 2.77 7840
RK151105 0.90 1.10 15.3 6.3 1600 900 2.45 2.85 9280
RK12904 0.90 0.90 12.3 9.5 1600 900 2.2 3.5 9600



High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation 0High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation 1

High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation 2High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation 3

High Temperture Polyester Mesh Belt Waste Water Treatment Solid Liquid Separation 4
