Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision

Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision
Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision

Large Image :  Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision

Product Details:
Place of Origin: Hebei,China
Brand Name: R&K
Certification: SGS
Model Number: Dutch-11
Payment & Shipping Terms:
Minimum Order Quantity: 1 squaremeter
Price: Negotiate
Packaging Details: Inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union,PayPal
Supply Ability: 1000 squaremeter per week
Detailed Product Description
Product Name: Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision Material: Stainless Steel Woven Mesh
Type: Weave Wire Mesh Hole Shape: Square Shape
Application: Screen Technique: Woven
Feature: Acid Resistant Hole: 30 Micorn
High Light:

30 micron stainless woven wire mesh

,

high precision stainless woven wire mesh

,

304 ss woven wire mesh

Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision







Product name 304 High Precision 30 Micron Stainless Steel Dutch Woven Wire Mesh
Type Stainless steel Dutch Woven wire mesh
Diameter 0.015 - 0.9mm
Hole Size 3 -347 micorn
Material low carbon steel wire, brass wire, nickel wire, stainless steel wire, polyester fiber
Mesh Count 7-3500 Mesh
Usage Protection mesh,filter
Color Silver
Size Customized
Sample Avaliable
Packing Individually packed in waterproof plastic bags
MOQ 1 meters
Delivery Tim 8-14 days
Processing Service Decoiling
Length 30m/roll
Width 1.0m
Weaving plain weave stainless steel dense mesh (plain-dense), twill weave stainless steel dense mesh (twill-dense), bamboo flower woven stainless steel dense mesh, contrast woven stainless steel dense mesh (also known as contrast mat type mesh conveyor belt )
Processing Service Plain Dutch Weave: Plain weave is similar to row weave. The difference is that the warp of this woven mesh is thicker than the weft. The weft threads are closely spaced together to form conical or wedge-shaped openings
Package carton
Application   For filters or sieves, such as fuel filters, vacuum filters, cast film filters, sewage treatment; Serving petroleum, aerospace, metallurgy, food, pharmaceutical and other industries; Conveyor belts for washing machines, dryers and sludge presses.
Feature Performance: acid resistance, alkali resistance, high temperature resistance, strong tensile force and wear resistance, stable filtration performance, fineness, high precision, and special filtration performance.





Parameters of stainless steel Dutch mesh

Mesh
(mesh/inch)
Warp×Weft)
Warp×Weft)
mm
Aperture Size
(um)
Effective section rate
(%)
Weight
(kg/m2)
Thickness
(mm)
7×,40 0,9×,0,71 347 14.3 6.65 2.32
7×,44 0,71×,0,63 319 14.2 5.55 1.97
8×,45 0,8×,0,6 310 15.5 5.7 2
8,5×,60 0,63×,0,45 296 20.3 4.16 1.53
8×,85 0,45×,0,315 275 27.3 2.73 1.08
10×,90 0,45×,0,28 249 29.2 2.57 1.01
10×,76 0,5×,0,355 248 21.8 3.24 1.21
12×,86 0,45×,0,315 211 20.9 2.93 1.08
12×,64 0,56×,0,4 16 3.89 1.36
12,5×,76 0,45×,0,355 192 15.9 3.26 1.16
14×,100 0,40×,0,28 182 20.3 2.62 0.96
14×,110 0,355×,0,25 177 22.2 2.28 0.855
14×,76 0,45×,0,355 173 14.3 3.33 1.16
16×,100 0,4×,0,28 160 17.7 2.7 0.96
17×,120 0,355×,0,224 155 22.4 2.19 0.803
16×,120 0,28×,0,224 145 19.2 1.97 0.728
20×,140 0,315×,0,20 133 21.5 0.715
20×,170 0,25×,0,16 130 28.9 1.56 0.57
20×,110 0,355×,0,25 126 15.3 2.47 0.855
22×,120 0,315×,0,224 115 15.5 2.2 0.763
25×,140 0,28×,0,2 100 15.2 1.96 0.68
24×,110 0,355×,0,25 97 11.3 2.6 0.855
28×,150 0,28×,0,18 92 15.9 1.87 0.64
30×,150 0,25×,0,18 82 13.5 1.79 0.61
30×,140 0,315×,0,20 77 11.4 2.21 0.715
35×,190 0,224×,0,14 74 16.8 1.47 0.504
35×,170 0,224×,0,16 69 12.8 1.62 0.544
40×,200 0,18×,0,135 63 15.4 1.24 0.43
45×,250 0,16×,0,11 56 15.2 1.11 0.384
50×,300 0,16×,0,09 55 20 0.98 0.34
60×,500 0,14×,0,055 51 34.1 0.7 0.252
50×,270 0,14×,0,10 50 15.2 0.98 0.34
70×,930 0,10×,0,03 30 36.2 0.39 0.16
65×,390 0,125×,0,071 42 19.1 0.78 0.267
60×,300 0,14×,0,09 41 14.1 0.96 0.32
80×,700 0,125×,0,04 40 38.1 0.6 0.205
60×,270 0,14×,0,1 39 11.2 1.03 0.34
77×,560 0,14×,0,05 38 27.5 0.74 0.24
80×,600 0,1×,0,045 37 29.8 0.53 0.19
70×,390 0,112×,0,071 16.3 0.74 0.254
65×,750 0,10×,0,036 36 37.1 0.43 0.172
70×,340 0,125×,0,08 35 13.2 0.86 0.285
80×,430 0,125×,0,063 32 16.6 0.77 0.251
100×,1200 0,063×,0,023 23 37.6 0.27 0.109
118×,750 0,063×,0,036 21.5 0.38 0.135







































































































































































Description of stainless steel Dutch woven wire mesh



The scientific name of the stainless steel mat mesh is dense mesh, and it is also called Helan cloth in the south of the Yangtze River or abroad. It is woven with stainless steel wire.Dutch steel wire cloth is also called filter cloth or micro cloth.



Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision 0

Grade 304 30 Micron Dutch Stainless Woven Wire Mesh High Precision 1
