Product Details:
Payment & Shipping Terms:
|
| Material: | Stainless Steel Wire Mesh | Type: | Weave Wire Mesh |
|---|---|---|---|
| Hole Shape: | Square Shape | Application: | Screen |
| Technique: | Woven | Feature: | Fuel Filter |
| Product Name: | High Strength 304 Material Dutch Woven Square Hole 70x600mesh For Filter Oil | Key Word: | Stainless Steel Ducth Mesh |
| High Light: | SGS ss 304 wire mesh,70x600 ss 304 wire mesh,304 stainless steel woven wire mesh |
||
High strength 304 material stainless steel dutch woven wire mesh
Description of stainless steel Dutch woven wire mesh
Ordinary Dutch woven mesh is made by weaving closed and warp threads of different diameters. Our wires have a small micron diameter and are woven with larger diameter warp threads. Our wire is tightly woven to produce a high-strength mesh while allowing
The thinner wires are in microns and are tightly woven together to provide a tight wire mesh for the filtering operation. Larger wires strengthen the mesh. Ordinary Dutch woven wire mesh is used to filter and separate liquids and slurries.
| Product name | High Strength 304 material Dutch Woven Square Hole 70x600mesh for filter oil |
| Key word | stainless steel dutch mesh |
| Feature | Fuel filter |
| Technique | Woven |
| Application | Screen |
| Hole shape | square shape |
| Type | Weave wire mesh |
| Material | stainless steel wire mesh |
Application of stainless steel Dutch wire mesh
Dutch wire mesh has endless applications in industry, commerce and decoration. Such as filters, sieves, separators, filters, baskets, gas diffusion, drying, car grill nets, vents, building and construction nets, craft paper, decorative nets, fan hoods, filtering liquids and gases, fireplace screens, food Dry, basic ventilation net, gutter protection net, high transparent net, hydraulic filter, insect net, lampshade, oil filter, pest control, safety, separation of fuel from water
Feature of the stainless steel Dutch wire mesh
1. High precision
2. The warp is larger than the diameter
3. The wefts may be close to each other
4. No pressure loss or no pressure loss during filtration
5. Highest filter surface
6. More stable than square and rectangular wire mesh
FAQ:
1.MOQ:No MOQ for sample order, from second time we can negotiate for it.
2.Packaging:We accept your private packaging with low cost.
3.Quality:Each product pass 5 times inspections at least before finishing to guarantee high quality.
4.Certification:Pass CE,RoHs,GS,FDA,LFGB,3C certification.
5.New Products:We design and product new products every year,
6.Delivery Time: On time delivery time, you can count on us.
7.Prices: Factory direct prices, the best cost to you.
Parameters of stainless steel Dutch mesh
|
Plain weave Dutch mesh |
||||
|
Number |
Mesh(warpxweft) |
Wire diameter (warpxweft) |
Aperture (um) |
Weight (kg/m2) |
|
32# |
8 x 62 |
0.63mm x 0.45mm |
300 |
5.42 |
|
40# |
10 x 79 |
0.50mm x 0.355mm |
250 |
3.16 |
|
48# |
12 x 64 |
0.58mm x 0.40mm |
280 |
2.9 |
|
55# |
14 x 88 |
0.40mm x 0.30mm |
180 |
2.54 |
|
76# |
19 x 140 |
0.315mm x 0.20mm |
140 |
1.88 |
|
80# |
20 x 300 |
0.35mm x 0.20mm |
- |
3.6 |
|
95# |
24 x 110 |
0.355mm x 0.25mm |
120 |
2.45 |
|
100# |
25 x 140 |
0.28mm x 0.20mm |
100 |
1.95 |
|
120# |
30 x 150 |
0.25mm x 0.18mm |
80 |
1.68 |
|
140# |
35 x 175 |
0.224mm x 0.16mm |
71 |
1.52 |
|
160# |
40 x 200 |
0.20mm x 0.14mm |
60 |
1.40 |
|
180# |
45 x 250 |
0.16mm x 0.112mm |
56 |
1.09 |
|
200# |
50 x 250 |
0.14mm x 0.11mm |
53 |
1.04 |
|
220# |
55.5 x 280 |
0.14mm x 0.10mm |
50 |
0.92 |
|
240# |
65 x 330 |
0.11mm x 0.08mm |
36 |
0.71 |
|
280#(1) |
70 x 350 |
0.11mm x 0.08mm |
35 |
0.72 |
|
280#(2) |
70 x 385 |
0.11mm x 0.07mm |
32 |
0.75 |
|
300# |
78 x 700 |
0.11mm x 0.08mm |
30 |
1.39 |
|
315#(1) |
80 x 400 |
0.10mm x 0.065mm |
40 |
0.62 |
|
315#(2) |
80 x 600 |
0.10mm x 0.06mm |
- |
0.74 |
|
315#(3) |
80 x 800 |
0.15mm x 0.04mm |
- |
0.77 |
|
320# |
81 x 780 |
0.10mm x 0.07mm |
30 |
1.22 |
|
354# |
90 x 550 |
0.12mm x 0.05 |
- |
0.667 |
|
Width:1m-1.6m |
||||
