High Flexibility Dutch Woven Twill Weave Stainless Steel Woven Wire Mesh

High Flexibility Dutch Woven Twill Weave Stainless Steel Woven Wire Mesh
High Flexibility Dutch Woven Twill Weave Stainless Steel Woven Wire Mesh High Flexibility Dutch Woven Twill Weave Stainless Steel Woven Wire Mesh

Large Image :  High Flexibility Dutch Woven Twill Weave Stainless Steel Woven Wire Mesh

Product Details:
Place of Origin: Hebei,China
Brand Name: R&K
Certification: SGS
Model Number: Dutch-02
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: Negotiate
Packaging Details: Inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union,PayPal
Supply Ability: 1000 squaremeter per week
Detailed Product Description
Product Name: High Flexibility Dutch Woven Twill Weave Stainless Steel Woven Wire Mesh Weave Style: Plain Weave Dutch Mesh, Twill Weave Dutch Mesh
Width: 1m, 1.2m, 1.5m, Or As Requirement Length: 30m Or As Requirement
Diameter: 0.9*0.71- 0.025*0.015 Usage: Fuel Filter
Keywords: Dutch Weave Wire Mesh Material: Stainless Steel 304 ,316
High Light:

high flexibility dutch woven wire mesh

,

width 1m twill weave wire mesh

,

high flexibility twill weave wire mesh

High Flexibility Dutch Woven Twill Weave Stainless Steel Woven Wire Mesh





Product description



Dutch wire mesh is also called cushion net, because its warp and weft diameters are different and the number of meshes is also different. The mat-shaped mesh can achieve the filtration density that cannot be achieved by the square-hole mesh by rationally matching different wire diameters and mesh numbers.



Product name High Flexibility Dutch Woven Twill Weave Stainless Steel Woven Wire Mesh
Material stainless steel 304 ,316
Mesh count 20*110,30*140,45*250
Weave Dutch Woven
Wire diameter 0.063-0.9
Hole size 3-347um



Product Application



It is used in precision pressure filters, fuel filters and vacuum filters for aerospace, petroleum, chemical, chemical fiber, rubber, tire manufacturing, metallurgy, medicine, food and other industries.



Product Feature



The mat network has many advantages in the control of ink flow. The same size of the mat type mesh is better for better control of ink precipitation, and it will also effectively avoid dot gain in the printing process, because even at the dot coverage rate. In higher areas, the overprinting rate of such outlets is still much lower than other outlets.

Another advantage of mat-type dots in screen printing is that all the dots are arranged next to each other instead of being stacked on top of each other as in the traditional mesh type. The reduction in stacking dots means that the lack of ink caused by the pressure at the top of the dots during the printing process is also alleviated.



Product parameters



plain weave Dutch mesh

Number

Mesh(warpxweft)

Wire diameter

(warpxweft)

Aperture

(um)

Weight

(kg/m2)

32#

8 x 62

0.63mm x 0.45mm

300

5.42

40#

10 x 79

0.50mm x 0.355mm

250

3.16

48#

12 x 64

0.58mm x 0.40mm

280

2.9

55#

14 x 88

0.40mm x 0.30mm

180

2.54

76#

19 x 140

0.315mm x 0.20mm

140

1.88

80#

20 x 300

0.35mm x 0.20mm

-

3.6

95#

24 x 110

0.355mm x 0.25mm

120

2.45

100#

25 x 140

0.28mm x 0.20mm

100

1.95

120#

30 x 150

0.25mm x 0.18mm

80

1.68

140#

35 x 175

0.224mm x 0.16mm

71

1.52

160#

40 x 200

0.20mm x 0.14mm

60

1.40

180#

45 x 250

0.16mm x 0.112mm

56

1.09

200#

50 x 250

0.14mm x 0.11mm

53

1.04

220#

55.5 x 280

0.14mm x 0.10mm

50

0.92

240#

65 x 330

0.11mm x 0.08mm

36

0.71

280#(1)

70 x 350

0.11mm x 0.08mm

35

0.72

280#(2)

70 x 385

0.11mm x 0.07mm

32

0.75

300#

78 x 700

0.11mm x 0.08mm

30

1.39

315#(1)

80 x 400

0.10mm x 0.065mm

40

0.62

315#(2)

80 x 600

0.10mm x 0.06mm

-

0.74

315#(3)

80 x 800

0.15mm x 0.04mm

-

0.77

320#

81 x 780

0.10mm x 0.07mm

30

1.22

354#

90 x 550

0.12mm x 0.05

-

0.667

Width:1m-2m
