Reproducible 110 Polyester Mesh For Solar Cell Printing

Reproducible 110 Polyester Mesh For Solar Cell Printing
Reproducible 110 Polyester Mesh For Solar Cell Printing Reproducible 110 Polyester Mesh For Solar Cell Printing Reproducible 110 Polyester Mesh For Solar Cell Printing

Large Image :  Reproducible 110 Polyester Mesh For Solar Cell Printing

Product Details:
Place of Origin: Hebei,China
Brand Name: R&K
Certification: FDA
Model Number: R&K-LSS
Payment & Shipping Terms:
Minimum Order Quantity: 50meters
Price: negotiation
Packaging Details: plastic bag inside, carton case outside,5-10rolls in one carton
Delivery Time: 5-8 work days
Payment Terms: L/C,T/T,Western Union,Paypal,Trade Assurance
Supply Ability: 3000 meters per week
Detailed Product Description
Material: 100% Polyester Name: 110 Cost-effective & Reproducible Screen Printing Mesh For Solar Cell Printing
Monofilament: Yes Application: Solar Cell Printing
Thread Diameter: 64um Color: Yellow
High Light:

110 screen printing mesh

,

reproducible 110 polyester mesh

,

solar cell printing 110 polyester mesh

110 Cost-effective & reproducible Screen Printing Mesh For Solar Cell Printing





Description of the 110 screen printing mesh:



Screen printing technology is the most effective, economical and most important technology in the production of solar cells. This is an important process in the front and back metallization layers. Our printing screen is a reliable and reproducible material in this process, and can be used for standardized and precise production.


We can provide you with 100% polyester screen printing mesh and stainless steel screen printing mesh to improve accuracy and reliability, produce solar panels, and meet mass demand with the continuous growth of the energy market.
Our solar cell screen printing screen can be used for the front metallization layer and the back metallization layer, and has the dual characteristics of cost-effectiveness and reproducibility.



Name 110 Cost-effective & reproducible Screen Printing Mesh For Solar Cell Printing
Material 100% polyester
Monofilament Yes
Application For Liquid Crystal Display
Thread Diameter 64um



Features of polyester screen printing mesh:



1. Faster turnaround time from the screen room to the pressroom;
2. Good diathermancy;
3. High air permeability;
4. Acid resistance and Alkali resistance;
5. Long working life;
6. Hard wear;
7. Three factories for manufacturing;
8. Imported weaving machines from Switzerland and Italy;

9. Low enlongation;

10. Acid resistant;



Specification of polyester screen printing mesh:


Mesh Count
Diameter
(Mesh/inch μm)
Mesh
Count
(Mesh
/Inch)
Weave Aperture
(μm)
Thread
Diameter
(μm)
Opening
(%)
Thickness(μm) Thickness
Tollerance
(+/- μm)
Theoretical
lnk(cm3/m2)
Weight
(g/m2)
13-150PW(SL) 33 1:1 619 150 64 300 14 128 60
21-80pw(S) 55 1:1 296 80 69 120 9 79 35
21-150PW(SL) 55 1:1 326 150 46 260 14 118 121
24-100PW(T) 60 1:1 316 100 57 136 11 65 81
28-140PW(SL) 70 1:1 217 140 40 195 13 76 125
32-55PW(S) 81 1:1 257 55 67 103 6 67 28
32-64PW(S) 81 1:1 248 64 63 95 6 56 32
32-100PW(T) 81 1:1 212 100 45 165 8 73 75
36-90PW(T) 92 1:1 183 90 44 150 8 65 68
39-55PW(S) 100 1:1 177 55 56 88 6 55 30
40-80PW(T) 103 1:1 166 80 44 133 7 59 60
43-80PW(T) 110 1:1 149 80 41 130 7 53 64
47-45PW(S) 120 1:1 166 45*2 61 80 6 42 40
47-55PW(S) 120 1:1 152 55 51 88 6 48 34
48-70PW(T) 122 1:1 133 70 41 115 6 47 55
53-45PW(S) 135 1:1 143 45*2 57 79 7 41 46
53-55PW(S) 135 1:1 133 55 50 86 6 42 40
54-64PW(T) 137 1:1 115 64 39 100 5 39 51
54-70(PW)HD 137 1:1 109 70 35 116 6 40 62
61-64PW(T) 155 1:1 90 64 31 101 5 30 58
64-55PW(S) 160 1:1 98 55 38 98 5 36 48
64-64PW(T) 160 1:1 85 64 30 115 6 34 61
68-55PW(S) 175 1:1 85 55 34 85 4 28 48
68-64PW(T) 175 1:1 78 64 28 105 5 30 65
72-48PW(S) 182 1:1 90 48 36 78 5 33 39
72-55PW(T) 182 1:1 85 55 30 90 5 27 51
77-48PW(S) 195 1:1 77 48 35 80 4 28 42
77-55PW(T) 195 1:1 67 55 27 88 4 24 55
80-48PW(T) 200 1:1 72 48 33 74 4 25 56
90-48PW(T) 230 1:1 56 48 25 78 4 19 50
100-40PW(T) 255 1:1 58 40 33 63 3 21 37
110-40PW(HD) 280 1:1 48 40 27 64 3 17 40
120-31PW(S) 305 1:1 49 31 35 49 3 17 26
120-34PW(T) 305 1:1 45 34 30 55 3 16 35
120-40PW(HD) 305 1:1 37 40 20 63 3 13 44
130-34PW(T) 330 1:1 40 34 27 55 3 15 37
140-31PW(S) 355 1:1 36 31 26 48 2 12 30
140-34PW(T) 355 1:1 31 34 20 53 3 10 39
140-34TW(T) 355 1:1 33 34 21 56 3 12 41
150-31PW(S) 380 1:1 32 31 23 49 3 11 32
150-34PW(T) 380 1:1 23 34 13 55 3 6.5 42
165-34PW(S) 420 1:1 23 31 15 48 2 7 36



110 sceen printing mesh manufacture proceess:



Raw material(Yarn)→ Warpping→Drawing in Heddle→Drawing in Reed→Weaving→Wahsing→Heat setting Treatment→Product Inspection→Product.



Application of the 110 screen printing mesh:



Ceramic Printing

Glass Printing

Textile Printing

Electronic Comeponeents Printing

PCB printing

Solar Printing

Touch Printing



Pre sale service:

  • Inquiry and consulting support.
  • Sample testing support.
  • View our Factory.

After sale service

  • Sending tracking number soon.
  • Training how to use it
  • Changing for new if dissatisfaction
