Product Details:
Payment & Shipping Terms:
|
| Name: | Polyester Dewatering Mesh Belt | Material: | 100% Polyester |
|---|---|---|---|
| Width: | Max Width 3.6m | Woven Way: | Weave |
| Color: | White Orange Blue | Size: | Length And Width Can Be Custmized |
| Weight: | 1.2KG-2.2KG/square Meter | ||
| High Light: | polyester dewatering conveyor belt,sludge dehydration dewatering conveyor belt,dewatering conveyor sludge dehydration belt |
||
Introduction:
Sludge Dehydration Fabrics is also called press-filter Fabrics which is mainly used for sludge dehydration, paper pulp and juice squeeze, Mine smelting, mine tailing disposal and other pressure filtration industries. They have the characteristics of good water permeability and non-revealed sludge, acid-resisting and alkali-resisting. Because of their designing structure, The sludge can be peel off easily from the filter cake, So the screen are easily cleaned and have a long working time. Mainly matching with belt type filter press, Vacuum rubber belt filter and horizontal vacuum belt filter.
It is an energy-saving and environmentally-friendly wire and mainly apply on sewage treatment in different industries .Its unique design structure can get high permeability for air & water but no sludge bleeding ,also the sludge easy to be removed after pressing then make the fabrics cleaner even has run long time , so can make long lifetime potential and stable run-ability .
Feature:
Material : 100% polyester mono filament
Type : Polyester Plain Weave Mesh /Fabric
Polyester Plain Weave Mesh /Fabric
Width: within 3.6 meter
Feature : Anti -Static, acid and alkali resis-
tance;tensile strength,permeability is good
Weight : 1.2-2.2kg/square meter
Density : 15-30wire/cm
Application : Sludge dehydration, paper pulp,
juice squeeze, mine smelting and other pressure
filtration industry
Color : White, blue
|
型号 Type
|
单丝直径 Wire Diameter(mm) |
密度(根/厘米) Density/cm |
Strength(N/cm) Tensile strength |
网重 Weight kg/m2 |
厚度 Thickness mm |
透气度 Air Permeability m3/m2h |
透气度 CFM 127/pa |
|||
|
经线 Warp |
纬线 Weft |
经线 Warp |
纬线 Weft |
网面 Surface |
接口 Joint |
|||||
| RK31505 | 0.40 | 0.50 | 33 | 9 | 1600 | 900 | 0.80 | 1.30 | 2976 | 186 |
| RK26508 | 0.50 | 0.50 | 28 | 18.5 | 1600 | 900 | 1.20 | 1.5 | 2050 | 128 |
| RK2470 | 0.50 | 0.70 | 24 | 9 | 1600 | 650 | 1.23 | 1.90 | 7520 | 470 |
| RK22903 | 0.50 | 0.90 | 23 | 5.5 | 1600 | 900 | 1.4 | 1.90 | 8480 | 530 |
| RK27708 | 0.50 | 0.70 | 28 | 8.5 | 1600 | 900 | 1.53 | 2.0 | 4896 | 306 |
| RK26908 | 0.50 | 0.90 | 26.2 | 6.2 | 1600 | 900 | 1.49 | 2.15 | 6080 | 380 |
| RK24908 | 0.50 | 0.90 | 24.8 | 7.1 | 1600 | 900 | 1.48 | 2.1 | 7360 | 460 |
| RK24808 | 0.50 | 0.80 | 24.8 | 8 | 1600 | 900 | 1.4 | 2.0 | 6880 | 430 |
| RK16903 | 0.70 | 0.90 | 16.3 | 5 | 1600 | 900 | 1.5 | 2.1 | 7520 | 470 |
| RK16903蓝色 | 0.70 | 0.90 | 16.3 | 5.8/6 | 1600 | 900 | 1.7 | 2.1 | 5550/3980 | 347/248 |
| RK15905 | 0.90 | 0.90 | 15.3 | 5 | 1600 | 900 | 2.1 | 2.77 | 7840 | 490 |
| RK151105 | 0.90 | 1.10 | 15.3 | 6.3 | 1600 | 900 | 2.45 | 2.85 | 9280 | 580 |
| RK12904 | 0.90 | 0.90 | 12.3 | 9.5 | 1600 | 900 | 2.2 | 3.5 | 9600 | 600 |
