White Color Polyester Dryer Mesh Belt For Fruit And Vegetables
Introcution:
The polyester plain weave 2-shed and 3-shed fabric is mainly used in special lines of paper making industry, Such as paper pulps making, packing and liner cardboard making, etc. Also can be used in mining industry for sieving or conveyor belt, high density board making, food drying, sludge dehydration machine, Concentrate and other filtration industries.
Polyester Monofilament process conveyor belting is available in a wide variety of yarn thicknesses and apertures. Polyester mesh
belting is characterised by high reliability, easy handling, thermal and chemical resistance
Usage:
1. filtering
2. Dewatering
3. washing
4. mining
5. Fruit and vegetables food drying
6. Paper making
Features:
1) Chemical, thermal resistance
2) Easy to clean
3) Working temperature: +150°C to -75°C in dry conditions. 70°C+ in wet conditions
4) Precise aperture from 0.5mm-2mm, good filtration ability.
5) Smooth running properties
6) Max. Width 6.0 M
7)Side treatment can be resin glued coated and canvas coated
8) Connection way: Clipper seam, pin rings, spiral rings, endless
|
Type |
Filament diameter mm |
Density/cm |
Weight Kg/m2 |
Thickness mm |
Aperture mm Warp/weft |
CFM 127Pa |
||
|
Warp |
Weft |
经线 Warp |
纬线 Weft |
|||||
| RK021002 | 1.0 | 1.0 | 2.85 | 2.65 | 0.6 | 1.85 | 2.5*2.77 | 2000 |
| RK031002 | 1.0 | 1.0 | 3.2 | 3.25 | 0.8 | 1.86 | 2.12*2.07 | 1600 |
| RK06802 | 0.8 | 0.8 | 6.6 | 6.5 | 0.85 | 1.45 | 0.72*0.73 | 725 |
| RK06702 | 0.7 | 0.7 | 7 | 7 | 0.77 | 1.3 | 0.72*0.72 | 690 |
| RK07802 | 0.8 | 0.8 | 7.8 | 7 | 1.1 | 1.45 | 0.32*0.54 | 370 |
| RK09502 | 0.5 | 0.5 | 9.7 | 10.3 | 0.5 | 0.9 | 0.53*0.47 | 634 |
| RK12502 | 0.5 | 0.5 | 13.5 | 8.5 | 0.63 | 1.95 | 0.24*0.65 | 6280 |
| RK09452 | 0.45 | 0.45 | 10 | 8.6 | 0.45 | 0.88 | 0.55*0.71 | 970 |
| RK08603 | 0.5 | 0.6 | 9.4 | 9 | 0.6 | 0.15 | 0.56*0.51 | 560 |
| RK08502 | 0.5 | 0.5 | 9.5 | 8.6 | 0.89 | 0.47 | 0.50*0.65 | 634 |
| RK06803 | 0.7 | 0.8 | 7 | 5.5 | 0.75 | 1.53 | 0.72*1.0 | 1000 |
| RK09603 | 0.5 | 0.5 | 10.5 | 9.2 | 0.65 | 1.05 | 0.45*0.48 | 518 |
