100% polyester mesh belt 3-layer formed fabric is suitable for high-speed paper machines

100% polyester mesh belt 3-layer formed fabric is suitable for high-speed paper machines

Product Introduction
Polyester Forming Fabric Polyester Forming Fabric is a key component in papermaking machines, crucial for paper sheet
formation and dewatering. It efficiently processes the pulp suspension from the headbox, facilitating the transformation
into paper. Made primarily from high - quality polyester monofilament, this fabric comes in various structures.
The single - layer type, with simple construction, offers good air permeability and drainage, widely used in basic paper
machine forming sections. Double - layer fabrics are designed to resist longitudinal load and horizontal wrinkling, ensuring
more stable operation. The two - and - a - half - layer and triple - layer options provide enhanced fiber support and durability.
For example, the additional top - layer CD yarns in two - and - a - half - layer fabrics boost fiber support and dehydration ability.
This fabric features excellent dimensional stability, high abrasion resistance on the wire side, minimum resistance to drainage,
and leaves minimal wire marks. It can be customized in terms of weave pattern, mesh count, thread diameter, surface topography,
and air permeability to meet different papermaking requirements. Its application temperature should be below 150ºC, with tension
controlled according to the layer type.

Product Description

A critical element in papermaking, Polyester Forming Fabric serves as the primary medium for pulp dewatering and sheet formation. Crafted from premium polyester monofilaments, it boasts exceptional durability and dimensional stability, withstanding the rigorous mechanical stresses of paper machines.

Available in diverse structures—single-layer, double-layer, 2.5-layer, and triple-layer—it caters to varied production needs. Single-layer designs excel in basic applications with efficient drainage, while multi-layer options enhance fiber retention and surface smoothness, ideal for high-quality paper grades. Its woven construction ensures uniform water flow, minimizing wire marks and optimizing sheet formation.

Resistant to chemicals and temperatures up to 150°C, this fabric maintains performance across different pulp types. Customizable in mesh count, thread diameter, and weave patterns, it adapts to specific paper weights and textures. A reliable choice for consistency, it reduces downtime and extends service life, making it indispensable in modern papermaking lines.

Product Features
