1x1 Hardware Fine 0.5m Stainless Steel Woven Wire Mesh

Large Image : 1x1 Hardware Fine 0.5m Stainless Steel Woven Wire Mesh

Product Details:

Place of Origin:	Hebei,China
Brand Name:	R&K
Certification:	ISO9001:2008,SGS,FDA
Model Number:	R&K-MB

Payment & Shipping Terms:

Minimum Order Quantity:	5 Square meters
Price:	Negotiate
Packaging Details:	Inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet
Delivery Time:	5-8 work days
Payment Terms:	L/C, T/T, Western Union,Paypal,Trade assurance.Credit card.
Supply Ability:	1000 square meter per week

Contact Now

Detailed Product Description

Product Name:	1x1 Hardware Fine Stainless Steel Wire 0.5m Stainless Steel Wire Mesh	Material:	304 Stainless Steel Wire Mesh
Type:	Weave Wire Mesh	Application:	Woven Wire Mesh
Wire Diameter:	0.8mm-5mm	Usage:	Filter
Width:	0,5m,1m,1,2m ,1,5m Or As Requirement	Length:	30m As The Standard One
Feature:	Corrosion Resistant	Hole Shape:	Square
High Light:	1x1 stainless steel woven wire mesh , hardware stainless steel woven wire mesh , 1x1 stainless woven wire mesh

High Tension Hardware Wire Mesh Corrosion Resistance Custom Width

stainless steel filter mesh description

Mterial: AISI 304

Wire diameter:0.035mm

Mesh count:347 mesh

Weave style: plain weave

stainless steel filter mesh Application

stainless steel filter mesh used in filtering liquid, gas and pulp.

Perhaps the most demanding industries for using stainless steel are the chemical, processing and oil and gas industries, which also create a huge market for stainless steel tanks, pipes, pumps and valves. One of the first success stories of 304 stainless steel is the storage of dilute nitric acid because it can be used in thinner parts and is stronger than other materials. Special grades of stainless steel have been developed to provide higher corrosion resistance at various temperatures. These are used in desalination plants, sewage treatment plants, offshore oil rigs, port support and ship propellers.

stainless steel filter mesh features

The most feature of the stainless steel fiter mesh is high tension,it's much higher than common polyester mesh.It have the uniform wire diamter for each mesh count.

Mesh	Wire Diameter		Aperture		Open Area	Weight
	Wire Diameter		Aperture		Open Area	Weight
	Inch	MM	Inch	MM	(%)	(kg /Square meter)
1x1	0.08	2.03	0.92	23.37	92	2
2X2	0.063	1.6	0.437	11.1	87.4	2.5
3X3	0.054	1.37	0.279	7.09	83.8	2.7
4X4	0.047	1.19	0.203	5.16	81.2	2.7
5X5	0.041	1.04	0.159	4.04	79.5	2.6
8X8	0.02	0.5	0.105	2.675	71	1
9X9	0.02	0.5	0.091	2.32	67.7	1.1
10X10	0.025	0.64	0.075	1.91	74.9	2
12X12	0.02	0.508	0.063	1.6	75.9	1.5
12X12	0.022	0.55	0.062	1.567	54.8	1.815
14X14	0.02	0.508	0.051	1.3	71.9	1.8
14X14	0.0177	0.45	0.054	1.36	75.14	1.417
16X16	0.016	0.4	0.047	1.188	55	1.28
16X16	0.018	0.457	0.0445	1.13	71.2	1.6
18X18	0.017	0.432	0.0386	0.98	69.4	1.6
20X20	0.02	0.24	0.03	0.76	76	0.56
20X20	0.016	0.33	0.034	0.86	72.2	1.1
20X20	0.014	0.35	0.036	0.92	52.5	1.225
20X20	0.016	0.4	0.034	0.87	46.9	1.6
20X20	0.0177	0.45	0.0322	0.82	41.7	2.025
22X22	0.012	0.3	0.034	0.854	54.76	0.99
24X24	0.014	0.35	0.028	0.708	44.77	1.47
30X30	0.014	0.35	0.0195	0.5	34.6	1.84
30X30	0.012	0.305	0.0213	0.54	63.9	1.4
30X30	0.0094	0.24	0.0243	0.62	72.1	0.84
35X35	0.0079	0.2	0.021	0.526	52.5	0.7
35X35	0.0098	0.25	0.0187	0.475	42.92	1.09
40X40	0.0079	0.2	0.017	0.435	46.9	0.8
40X40	0.01	0.254	0.015	0.38	59.9	1.3
40X40	0.014	0.35	0.011	0.285	20.14	2.45
50X50	0.0055	0.14	0.0145	0.368	72.4	0.48
50X50	0.0079	0.2	0.012	0.308	36.76	1
60X60	0.0047	0.12	0.012	0.303	71.6	0.42
60X60	0.0059	0.15	0.0107	0.273	64.5	0.65
60X60	0.007	0.18	0.0096	0.243	33	0.972
80X80	0.047	0.12	0.0078	0.1975	38.7	0.576
80X80	0.0055	0.14	0.0069	0.117	45.5	0.76
100X100	0.0039	0.1	0.006	0.154	36.76	0.5
100X100	0.0045	0.114	0.0055	0.14	55.1	0.59
100X100	0.004	0.102	0.006	0.152	59.8	0.49
120X120	0.0028	0.07	0.0057	0.147	67.7	0.29
120X120	0.003	0.08	0.0052	0.132	38.7	0.384
150X150	0.0024	0.06	0.0043	0.11	64.7	0.26
150X150	0.0028	0.07	0.0039	0.1	58.8	0.38
165X165	0.0019	0.05	0.0041	0.104	67.5	0.2
180X180	0.0019	0.05	0.0035	0.091	64.5	0.22
180X180	0.0024	0.06	0.0031	0.081	57.4	0.32
200X200	0.0019	0.05	0.003	0.077	60.6	0.24
200X200	0.0024	0.06	0.0026	0.067	52.7	0.35
250X250	0.0016	0.04	0.0024	0.0616	60.6	0.2
270X270	0.0016	0.04	0.0021	0.054	57.4	0.21
300X300	0.0016	0.04	0.0018	0.045	53.5	0.23
325X325	0.0014	0.035	0.0017	0.0432	55.3	0.2
400X400	0.0012	0.03	0.0013	0.0335	52.7	0.18
500X500	0.0009	0.025	0.001	0.0258	50.7	0.15
500X500	0.0012	0.03	0.0008	0.0208	16.76	0.225
635X635	0.0007	0.018	0.0008	0.022	55	0.1
